SCBH15-1000KVA amorphous alloy dry-type transformer in detail

In the field of power transmission and distribution, transformer is a key equipment, and its performance and quality are directly related to the stability and safety of the entire power system. In recent years, with the continuous progress of technology and the continuous changes of the market, SCBH15-1000KVA amorphous alloy dry-type transformer has attracted extensive attention due to its unique advantages. This article will make an in-depth analysis of SCBH15-1000KVA amorphous alloy dry-type transformer, including its structural characteristics, technical advantages, application fields and market prospects.

First, structural characteristics

SCBH15-1000KVA amorphous alloy dry-type transformer adopts advanced technology and materials, and has many unique structural features. First of all, its core is made of imported cold-rolled silicon steel sheets, which greatly reduces the full-load and no-load currents and improves the efficiency of the transformer. At the same time, the core is bundled to ensure its compactness and stability, and reduce the generation of noise. Secondly, the high and low voltage winding is made of oxygen-free copper, and the low-voltage winding is less than 500KVA, and the double or quadruple spiral structure is selected when the low voltage winding is below 500KVA, and the double or quadruple helix structure is selected when it is 630KVA and above, which makes the winding more compact and has better heat dissipation performance. The high-voltage winding adopts a double-layer barrel structure, which improves the voltage resistance of the transformer. In addition, the transformer uses the Dyn11 connection class, which reduces the impact of harmonics on the grid and improves the quality of power supply. Finally, the transformer is a fully sealed structure, no need for core inspection, maintenance-free, and greatly prolongs the service life.

Second, technical advantages

SCBH15-1000KVA amorphous alloy dry-type transformer has many advantages in technology. First of all, amorphous alloy materials have excellent soft magnetic properties, corrosion resistance, wear resistance and high resistivity, which makes the transformer have lower no-load loss and higher efficiency. Secondly, the transformer adopts advanced production technology and strict quality control system to ensure the stability and reliability of the product. In addition, its compact structure, good heat dissipation performance, low noise and other characteristics also make it more stable and reliable in the application process. Finally, the transformer also has the characteristics of environmental protection, flame retardant, explosion-proof, maintenance-free, etc., which meets the environmental protection requirements of modern power systems.

Third, the field of application

SCBH15-1000KVA amorphous alloy dry-type transformer is suitable for various power transmission and distribution occasions. Due to its advantages of high efficiency, energy saving, environmental protection, etc., it is especially suitable for use in the power system of high-rise buildings, commercial centers, airports, oil platforms, subway tunnels, industrial and mining enterprises and power plants. In addition, the transformer is also suitable for installation and use in places with high fire protection requirements such as flammable and explosive, which improves the safety and reliability of the power system.

Fourth, the market prospects

With the rapid development of the power industry and the continuous improvement of environmental protection requirements, SCBH15-1000KVA amorphous alloy dry-type transformer has broad market prospects, as a high-efficiency, energy-saving and environmentally friendly power equipment. In the future, the transformer will play a more important role in the power system and make greater contributions to the development of the power industry. At the same time, with the continuous progress of technology and the continuous changes of the market, SCBH15-1000KVA amorphous alloy dry-type transformer will also continue to carry out technical upgrades and performance optimization to meet the needs of the market and customers.

To sum up, SCBH15-1000KVA amorphous alloy dry-type transformer, as a high-efficiency, energy-saving and environmentally friendly power equipment, has a wide range of application prospects in the field of power transmission and distribution. Its unique structural characteristics and technical advantages make it play an increasingly important role in the power system.
