SCB18-2000KVA dry-type power transformer uses high-quality materials and production, and has a very high service life and stability. The edge material of SCB18-2000KVA dry-type power transformer is made of high-temperature dry-solid material, which has strong temperature resistance and durability, and can work at high temperature for a long time without aging and dry cracking. At the same time, the wire is made of high-purity copper material, which has very good conductivity and effectively reduces energy loss.

Characteristic:

High energy efficiency: SCB18-2000KVA dry-type power transformer adopts high-efficiency design and low-loss materials, which can achieve higher energy consumption levels.

High reliability: SCB18-2000KVA dry-type power transformer adopts advanced insulation materials, which can effectively avoid faults such as electrical orphanage, penetration and short circuit, so as to ensure high reliability and long life of the system.

Safety and environmental protection: SCB18-2000KVA dry-type power transformer does not use insulating oil, which prevents the risk of oil leakage or environmental pollution, and is safer and more environmentally friendly.

Low noise: SCB18-2000KVA dry-type power transformer adopts special noise reduction materials, which can effectively control noise and reduce harmonics and interference signals at the same time.

Large capacity: SCB18-2000KVA dry-type power transformer has a high capacity and can meet the needs of a variety of power supply systems.

Product Usage:

SCB18-2000KVA dry-type power transformer is manufactured according to the specification “Dry-type Power Transformer”, which features low consumption, good energy-saving effect, economical operation and maintenance-free. In addition to the advanced process structure, high level of anti-short circuit and lightning impact, it also has the characteristics of flame retardant, moisture-proof, foul-resistant, low noise, etc., and can penetrate deep into the load center. It is widely used in high-rise buildings, airports, stations, ports, power plants, distribution stations, etc. It is especially suitable for site installation applications with strong fire protection requirements such as flammable and explosive.

The standard transformers produced by the company are without housing, and the protection level is IP00, and the protection level of IP20 and IP23 can be provided if the user needs. The shell can be made of general steel plate, stainless steel plate, aluminum alloy and other materials according to customer requirements, and is pickled, phosphated, sprayed and other treatments. The temperature control indicator and load recorder are installed on the low-voltage side of the shell, which is convenient for users to observe, safe and reliable.

Performance Parameters:

1. Key performance parameters of SC(B)10 type are shown in the table;.

2. Number of phases: 3 phases.

3. Frequency: 50Hz; 4.

4. Insulation and heat resistance grade: F grade.

5. Winding resistance mean value temperature: W100K.

6. Partial discharge: less than 5pc.

SCB18-2000KVA dry-type power transformer is our company introduced foreign cutting-edge technology, independently developed SC9, SCB9 series and its SC1O, SCB1O series with packing thin insulation dry-type transformer, because the coil is wrapped in epoxy resin, so flame retardant, fireproof, explosion-proof, maintenance-free, small size, can be directly installed in the load center. At the same time, the scientific and reasonable design and pouring process make the product have small partial discharge, low noise, strong heat dissipation capacity, and can operate for a long time under 140% rated value in the forced air-cooling environment, and is equipped with an intelligent temperature controller, with fault alarm, overheating report, overheating trip and its black gate function, and through RS485 serial communication and computer connection, can be centrally monitored and controlled.
