Product description
The S22-1600KVA oil-immersed transformer cancels the oil conservator, and uses the fins of the corrugated oil tank itself as the heat exhaust and refrigeration components, and surges with the adjustment of the transformer oil, so that the internal structure of the transformer and atmospheric protection can avoid oil deterioration and insulation layer resurgence and aging, and strengthen the stability of operation. The core of the S22-1600KVA oil-immersed transformer is made of very good cold-rolled ferrite core, which optimizes the magnetic induction intensity inside the core, reduces noise and consumption.
The S22-1600KVA oil-immersed transformer has the following features:
1. Double-roll structure: S22-1600KVA oil-immersed transformer adopts double-roll overall design, and the high and low voltage windings are immersed in transformer oil, which effectively ensures the insulation reliability of the transformer.
2. The core of the core is made of triangular structure: the core of the S22-1600KVA oil-immersed transformer is designed with a triangular structure, which effectively reduces the magnetic leakage and noise, and improves the efficiency and operation reliability of the transformer.
3. Reliable insulation layer material: S22-1600KVA oil-immersed transformer is made of thermal conductive materials and transformer oil with strong electrical characteristics and insulation, which can effectively extend the service life and maintenance cycle of the transformer.
4. Strong adaptability: S22-1600KVA oil-immersed transformer can be mainly used in power system places, such as power supply and distribution systems, industrial applications and rural areas.
5. Easy maintenance: The machine, electrical equipment and insulation part of the S22-1600KVA oil-immersed transformer can be disassembled and maintained, which has high scalability and stability.
S22-1600KVA oil-immersed transformer is an upgraded enterprise product of power distribution equipment transformer, no-load loss and load loss are significantly reduced, S22-1600KVA oil-immersed transformer is nearly 20%-30% more power-saving than S13 transformer. This requires the S22-1600KVA oil-immersed transformer to choose more advanced raw materials, first-class design schemes, and more first-class manufacturing and processing technology.
1. Iron core ferrite core
S22-1600KVA oil-immersed transformer needs to use 80 or even 75 ferrite core raw materials, and S13 transformers generally use 85 ferrite core raw materials, which makes the two types of transformer core engineering costs thousands or even tens of thousands of yuan, and the ferrite core depends on the transformer no-load loss.
2. The construction drawing design plan of the first class
Using the new design scheme, ferrite core material design, the same transformer winding resistance in the material, net weight will be different, the transformer winding resistance is not the same depends on the load loss of the transformer, S22-1600KVA oil-immersed transformer load loss is reduced by 10% compared with S13 transformer.
S22-1600KVA oil-immersed transformer requires ferrite core raw material model specifications
3. Advanced processing technology
While the no-load loss and load loss of S22-1600KVA oil-immersed transformer decrease, higher requirements are also put forward for the transformer manufacturing and production process, including the core production process, high-voltage ignition line pouring steps, the difficulty of core assembly and test items.
The price of S22-1600KVA oil-immersed transformer is about 40% more expensive than that of S13 transformer with the same volume, but the consumption of the transformer is much less in operation, in other words, although the price of S22-1600KVA oil-immersed transformer is high, it can save customers a lot of money in the loss of water and electricity bills, and the total cost is not as good as burning money with S13 transformer.
