SCB14 dry-type power transformer is a model that meets the second-level energy consumption of dry-type transformer in the “GB20052-2020 National Standard for Energy Efficiency Limits and Energy Efficiency Grades”, and the second-level energy-efficient silicon steel sheet transformer, SCB14 dry-type power transformer has a 15% reduction in no-load loss and a 10% reduction in load loss compared with SCB12 transformer that meets third-level energy efficiency.

Applicable Scenarios:

SCB14 dry-type power transformer is cast with epoxy resin, which has the characteristics of low loss, good energy-saving effect, economical operation and maintenance-free, and is used in high-rise buildings, airports, stations, docks, power plants, substations and other places with high fire protection requirements.

Advantages of SCB14 dry-type power transformer:

1. SCB14 dry-type power transformer loss***

The SCB14 dry-type power transformer uses a higher grade of silicon steel sheet, which reduces the no-load loss by 15% compared with SCB12 and the load loss by 10% compared with SCB12 transformer.

2、SCB14 dry type power transformer noise***

Due to the innovation of the production process, the normal operation of the equipment is 10 to 15 decibels lower than the current standard “6-220kV transformer sound level”.

SCB14 dry-type power transformer features:

1. Good energy saving, power saving effect is remarkable

The core of SCB14 dry-type power transformer is made of 80 grade silicon steel sheet, and the iron loss is greatly reduced, and the no-load and load loss are reduced by about 15% and 10% respectively compared with SCB12 dry transformer. SCB14 dry-type power transformer due to its ultra-high efficiency, energy-saving characteristics, at an average load of 75%, 3-5 The additional investment can be recovered during the year, which can save a lot of electricity bills every year.

2. High reliability, insulation grade F

SCB14 dry-type power transformer meets the national standards GB1094.11-2007, GB/T22072-2008 and IEC60076-11 Standard; The product is H class (working temperature 180°C) heat resistance grade, with good short circuit resistance; The transformer is maintenance-free under normal use.

3. Good safety, flame and explosion proof

SCB14 dry-type power transformer will not support combustion in use, can be flame retardant, will not explode and emit harmful gases; When the transformer is used, it will not cause harm to the environment and other equipment, especially to people.

4. Low noise, low partial discharge

The noise level of SCB14 dry-type power transformer is more than 10-15 decibels lower than the current professional standard JB/T10088-2016 “6-220KV transformer sound level”. The product only has a very low partial discharge capacity, which can be controlled below 5PC.
