SCB12-1600KVA dry-type power transformer is a dry-type transformer with chromatography epoxy resin pouring to wrap high and low voltage windings, with reasonable design, advanced technology, small partial discharge, low noise, flame retardant, self-extinguishing, moisture-proof, strong heat discharge, maintenance-free, zero pollution and other characteristics. The surface of the core and clamp of SCB12-1600KVA dry-type power transformer is specially treated with protective resin and has a beautiful appearance. The low-pressure foil winding and high pressure are segmented double-layer barrel structure, so that the ampere turns are evenly balanced, the magnetic flux leakage is small, the impact toughness is high, and the short-circuit resistance is strong.

SCB12-1600KVA dry-type power transformer structure:

High voltage windings

The high-voltage winding is vacuum poured with filler epoxy resin, the local discharge is small, the electrical strength of the coil is high, and the glass fiber network grating is used to improve the inner and outer walls, which enhances the impact toughness of the coil, improves the ability of the commodity to resist sudden short circuit, and the coil will never dry out.

Low-voltage windings

The low-voltage winding adopts a foil structure, which solves the problem of radial helix angle when using wire, so that the coil is made of radial refrigeration duct at the same time, which improves the heat loss capacity, and the DMD epoxy pre-diffuse cloth is used for the winding and solid layer, and the overall dry solid molding is made.

Core

The core is made of imported high-quality cold-rolled silicon steel sheet, the third-order gold mitered structure, the core pillar fruit is used for F-grade non-mold ceremony, and the surface of the core is wrapped by epoxy tree, which reduces the no-load loss, and the no-load current and the core of the city and fasteners are treated with a special surface layer, so that the appearance quality of the product is further improved.

Temperature-controlled system and air-conditioning system

The diffuse top blowing cooling fan is selected, which has the characteristics of low noise, high air pressure and beautiful appearance, which improves the load capacity of the transformer. The intelligent temperature controller is used for temperature control, which improves the reliability of transformer operation.

SCB12-1600KVA dry-type power transformer features:

1. Safe, fireproof, zero pollution, can operate directly in the load center;

2. The advanced production technology is selected, with high impact toughness, strong short-circuit resistance, small partial discharge, good thermal stability, high reliability, and strong and durable;

3. Low loss, low noise, significant energy-saving effect, maintenance-free;

4. Good heat dissipation performance, strong overload capacity, and 50% increase in volume operation when forced air cooling;

5. Good moisture-proof performance, adapt to high humidity and other extreme environments;

6. Small size, light weight, less floor space, low installation cost.

SCB12-1600KVA dry-type power transformer is independently developed by our company with cutting-edge technology, the core is made of high magnetic permeability and high-quality grain orientation cold-rolled silicon steel sheet, 45° full oblique stepping joint, the core is made of special square tube pull plate structure, the core column is bundled with insulating tape, and the surface of the core is coated with unique resin to prevent moisture and rust, which effectively reduces the no-load loss, no-load current and core noise. At the same time, the scientific and reasonable design and pouring process make the product smaller, low noise, strong heat dissipation ability, and long-term operation under the rated value in the forced air-cooling environment.
