S22-16000KVA oil-immersed transformer is an efficient, stable and widely used power equipment, which plays a vital role in the process of power generation, transmission, transformation and distribution of power system. With excellent performance characteristics and a wide range of applications, this transformer is able to meet the power needs of large industrial, commercial and urban power grids.

First of all, from a structural point of view, the S22-16000KVA oil-immersed transformer adopts an advanced oil-immersed design, so that its internal coil and core can be fully cooled and insulated, so as to ensure that the transformer can operate stably for a long time. In addition, its unique core design, such as the use of cold-drawn crystal-oriented silicon steel sheets, reduces losses and noise, and improves the efficiency of the transformer. At the same time, the 45° full miter joint, no hole and epoxy resin belt bundling structure, as well as the application of core plating paint on the core surface, also further improve the performance and stability of the transformer.

In terms of performance, the S22-16000KVA oil-immersed transformer shows its superior side. It uses an all-copper coil, which makes the resistor wind, which reduces energy loss and improves the efficiency of the transformer. In addition, its larger oil tank size allows the transformer to better dissipate heat and avoid damage caused by over-temperature, ensuring the stable operation of the transformer in high-temperature environments. At the same time, the transformer can withstand higher loads and export more output power to meet large power demands.

In terms of energy saving, the S22-16000KVA oil-immersed transformer also performs well. It selects a five-grade silicon steel sheet joint with excellent performance, improves the core structure and process, reduces the process index, and thus reduces the full load loss. At the same time, the conductor pulled by the oxygen-free copper rod with stronger conductivity than electrolytic copper is used to improve the conductivity, adjust the current intensity appropriately, improve the insulation structure, and further reduce the load loss. In addition, by improving the key structure, controlling the magnetic flux leakage of the windings, adjusting the ampere-turn balance, and selecting the design of the wave type fuel tank and the seat radiator, the losses of other components are effectively reduced and the overall energy efficiency is improved.

In terms of daily maintenance, the S22-16000KVA oil-immersed transformer also has its unique advantages. For example, its oil tank has a bellows design with a breathing function that compensates for changes in the volume of oil due to temperature changes, which reduces the height of the transformer and simplifies the maintenance process. At the same time, the corrugated sheet replaces the oil conservator, isolating the transformer oil from the outside world, effectively preventing the entry of oxygen and moisture, and ensuring the stability of insulation performance. In addition, the transformer’s cover is constructed with a ring-shaped overlock seam for a symmetrical force and reliable sealing, further enhancing its durability and safety.

In terms of application fields, S22-16000KVA oil-immersed transformer is widely used in various fields because of its high efficiency, stability and environmental protection. It can not only be used for the power output of large power plants, but also realize the rise and fall conversion of voltage to ensure the safety and stability of power transmission; It can also be applied to the voltage conversion of substations to meet the conversion requirements between different voltage levels; In addition, in large industrial enterprises and urban power grids, S22-16000KVA oil-immersed transformers also play a vital role in providing stable and reliable power supply for all kinds of electrical equipment.

However, despite the many advantages of the S22-16000KVA oil-immersed transformer, there are still some issues that need to be paid attention to during use. For example, transformers need to be regularly maintained and inspected to ensure that they are in good operating condition; In the process of installation and use, it is necessary to strictly abide by relevant norms and standards to ensure safety and reliability; At the same time, it is also necessary to pay attention to the heat dissipation problem of the transformer to avoid failures caused by poor heat dissipation.

To sum up, the S22-16000KVA oil-immersed transformer plays an irreplaceable role in the power system with its efficient, stable and environmentally friendly performance characteristics and wide application range. With the continuous growth of power demand and the continuous progress of technology, the S22-16000KVA oil-immersed transformer will continue to play its important role and make greater contributions to the safe, stable operation and sustainable development of the power system.
