S20-2500kVA oil-immersed transformer is a common power equipment, which is widely used in power system voltage boost, voltage reduction and voltage transformation and other application scenarios. The following will introduce the characteristics, advantages, application scenarios, precautions and maintenance of S20-2500kVA oil-immersed transformer in detail from multiple aspects.

1. Characteristics of S20-2500kVA oil-immersed transformer

Rated capacity: S20-2500kVA, it is a large-capacity transformer, which can meet the needs of large-scale power systems.

Cooling method: The oil immersion cooling method is adopted, that is, the coil and iron core inside the transformer are impregnated with oil, and the heat is dissipated through the circulating cooling of the oil.

Insulating material: Mainly paper insulating material, which has high electrical performance and heat resistance.

Structural features: S20-2500kVA oil-immersed transformer usually adopts a heart-type structure, which is simple, compact and easy to maintain.

2. Advantages of S20-2500kVA oil-immersed transformer

High efficiency: Due to the oil-immersed cooling method, the transformer can quickly dissipate heat and improve operating efficiency.

Large capacity: The rated capacity of S20-2500kVA can meet the needs of large-scale power systems.

High reliability: Due to its simple structure, compact structure and easy maintenance, it has high reliability.

Low cost: Oil-immersed transformers are less expensive to manufacture than other types of transformers.

3. Application scenarios of S20-2500kVA oil-immersed transformer

Power system: S20-2500kVA oil-immersed transformer is mainly used in application scenarios such as voltage boost, step-down and voltage transformation of power system.

Industrial: It is widely used in industrial fields, such as steel, petrochemical and other industries that require a large amount of power supply.

Commercial: S20-2500kVA oil-immersed transformers are also used in shopping malls, office buildings and other commercial facilities to meet power demand.

4. Precautions for the use of S20-2500kVA oil-immersed transformer

Safe operation: In the process of operation, it is necessary to follow the safety operation procedures to prevent safety accidents. At the same time, the operation status of each component of the transformer should be checked regularly to ensure its safe and stable operation.

Maintenance: Perform regular maintenance, including cleaning the appearance, checking fasteners, checking the oil level, etc. At the same time, the transformer oil should be changed regularly to maintain the cleanliness and quality of the oil.

Operating environment: The transformer should be installed in a dry, well-ventilated, non-corrosive gas environment. In addition, maintain proper indoor temperature and humidity to prevent the transformer from overheating or getting wet.

Prevent overload: The transformer should be avoided from running overload for a long time, so as not to cause damage to the equipment or shorten the service life.

Prevention of lightning hazards: During the thunderstorm season, lightning protection measures should be taken to avoid damage to the transformer caused by lightning.

5. Maintenance of S20-2500kVA oil-immersed transformer

Visual inspection: Regularly check whether the appearance of the transformer is in good condition, whether there is leakage, deformation, etc.

Oil level check: maintain a proper oil level, regularly check whether the oil level is normal, if the oil level is too low or too high, it should be dealt with in time.
