2500KVA amorphous alloy dry-type transformer is a new type of environmentally friendly and energy-saving transformer, 2500KVA amorphous alloy dry-type transformer integrates the advantages of amorphous alloy material without consumption and traditional epoxy resin glue cast transformer in various aspects such as large insulation and impact toughness. The no-load loss is 75~80% lower than that of the ordinary 10 series dry-type transformer, and the no-load current is reduced by 80%.

Nature of work

●Operating temperature

Bright temperature +40°C

Temperature -25 ° C

The average temperature of a Thermidor Moon is +30°C

The average annual temperature of the hot is +20°C

● The altitude should not exceed 1000m

●The waveform of the supply current is infinitely close to the sine waveform

●The power supply current of the three-phase power supply should be approximately symmetrical

●There is no obvious pollution in the use environment

● Indoor applications

Structural features

The low voltage of 2500KVA amorphous alloy dry-type transformer is foil coil, copper coil inductance is selected, H-grade high-toughness wire-wrapped wire coil inductor is selected for high-voltage ignition wire, and epoxy resin glue is wrapped with glass fiber reinforcement, which has good water resistance and cohesion performance. The core is made of amorphous alloy amorphous strip coiled, and is constructed with square cross-section, four-frame five-column or three-frame three-column construction.

Product Features:

1. Low consumption, environmental protection and energy saving: the use of anisotropic soft strip magnetic permeability material, the magnetization power is small, the core is made of amorphous alloy material, and the no-load loss and no-load current are low.

2. Strong short-circuit resistance: three-phase five-column structure is selected, and frame shear wall is selected around the core for maintenance, and the structure is simple and effective.

3. Equipped with a variety of equipment: according to customer requirements, it can be set up with general thick steel plates, aluminum alloy profiles or stainless steel shells, and the waterproof level is IP20, IP23, etc., and the high-voltage and low-voltage bus inlet and outlet sockets can be configured according to user needs.
